How to troubleshoot Yaskawa SGDH-04AE-OY servo drive failure to enable?
When the Yaskawa SGDH-04AE-OY fails to power on, the servo fails to enable, the motor vibrates, or the drive alarms, the power supply, parameters, motor, encoder, and mechanical load should be checked in sequence.

The SGDH-04AE-OY is a Yaskawa Sigma-II series servo drive. When the device fails to enable, the drive unit itself, motor cables, encoder feedback, control signals, and parameter settings can all produce similar symptoms.
The key to on-site diagnosis is first determining the fault scope, then deciding on the repair target. During the inspection process, record alarms, axis numbers, robot posture, and recurrence conditions to avoid replacing components based solely on a single alarm.
- Common Fault Symptoms
- Drive has no display or alarms immediately after power-on.
- Servo enable signal is valid but the motor cannot run.
- Motor runs with vibration, increased noise, or inaccurate positioning.
- Overcurrent and overload occur during acceleration, deceleration, or under load.
- Possible Causes
- Main power or control power supply abnormal.
- Enable, limit, or safety signals not satisfied.
- Incorrect wiring or poor contact in motor and encoder connections.
- Parameters do not match the motor model.
- Excessive mechanical load or damaged drive power circuit.
- On-site Troubleshooting Sequence
- Record drive alarms and the phase when the fault occurs.
- Check input power, control power, and enable signals.
- Verify motor model, power cables, encoder cables, and drive parameters.
- Compare operating status after disconnecting or reducing the mechanical load.
- After external conditions are confirmed normal, then test the internal circuit of the SGDH-04AE-OY.
- Verification Before Replacing Components
Save parameters before replacement, and verify input voltage, capacity, control method, matching motor, interface options, and the complete model suffix.
Similar external appearance does not mean direct interchangeability. Before procurement, provide the equipment's complete model number, original component nameplate, interface photos, controller model, and alarm information.
- Post-repair Verification
First perform no-load low-speed operation, then test positioning, acceleration/deceleration, and rated load, confirming that current, temperature, direction, and alarm status are normal.
After repair is complete, also save the test results, replacement part numbers, and final parameters to facilitate tracking by subsequent maintenance personnel.
- Summary
When handling such faults, troubleshoot in the order of alarm records, power supply and connections, feedback lines, mechanical load, and the component itself. Only after external conditions are confirmed normal can you further determine if the target component needs repair or replacement.
